This NXP board is based on the KL25Z128VFM4 which is a 48MHz device from the ultra-low-power KL family with Cortex-M0+ core and USB. This KL25 device has 128k Flash and 16k SRAM and is in an 32 pin QFN package, whereby the KL25 is also available in various other LQFP packages (32, 48, 64 pins) and its memory ranges from 32k ..256k Flash and 4k ..32k SRAM. There is an 8MHz crystal on the board for clocking the part.

Full details and documentation for this board can be obtained from the Freescale web site: RD-KL25-AGMP01

To configure the µTasker project for this board simply enable the define RD_KL25_AGMP01 in the project's config.h file. The compiler needs to be set to build for Cortex M0+ (and not Cortex M4) and the linker script KL_128_16.ld should be selected [KL_128_16_BM.ld for downloadable version] {the linker script extension may vary for different compilers, whereby *.ld is valid for GCC}

RD-KL25-AGMP01 Binaries

Support for this board is presently in the development phase - please come back later or contact us for more information using an email address found at the botom of the home page.
